Specifications

• Dimensions

  add remove
  • Length:
    2340 mm
  • Seat height, unladen:
    710 mm
  • Ground clearance:
    120 mm
  • Rake:
    28
  • Trail:
    132 mm
  • Wheelbase:
    1615 mm
  • Tyres, front specifications:
    150/80-16,71H,BW
  • Tyres, rear specifications:
    180/70B16,77H,BW
  • Fuel capacity:
    13.2 l
  • Oil capacity:
    4.4 l
  • Weight, as shipped:
    296 kg
  • Weight, in running order:
    306.17 kg
  • Tyre, type:
    Dunlop^™ Harley-Davidson Series, bias blackwall front and rear
• Engine

  add remove
  • Engine:
    Milwaukee-Eight^™ 114
  • Bore:
    102 mm
  • Stroke:
    114.3 mm
  • Displacement:
    1868 cm³
  • Compression ratio:
    10.5:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-into-2 shorty dual; catalyst in muffler
• Performance

  add remove
  • Engine torque testing method:
    EC 134/2014
  • Engine torque:
    155 Nm
  • Engine torque (RPM):
    3500
  • Horsepower:
    93 HP / 69 kW @ 5020 rpm
  • Lean angle, right (deg.):
    31
  • Lean angle, left (deg.):
    32
  • Fuel economy testing method:
    EU 134/2014
  • Fuel economy:
    5.5 l/100 km (43 mpg)
  • CO₂ emissions testing method:
    EU 134/2014
  • CO₂ emissions:
    128 g/km CO₂
• Drivetrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    9.311
  • Gear ratios (overall) 2nd:
    6.454
  • Gear ratios (overall) 3rd:
    4.793
  • Gear ratios (overall) 4th:
    3.882
  • Gear ratios (overall) 5th:
    3.307
  • Gear Ratios (overall) 6th:
    2.79
• Chassis

  add remove
  • Front fork:
    Single cartridge 43 mm inverted with aluminum fork triple clamps; triple rate spring
  • Rear shocks:
    Hidden, free piston, coil-over monoshock; 56mm stroke; toolless hydraulic preload adjustment
  • Wheels, front type:
    Denim black, Structure cast aluminum with laser etched graphics
  • Wheels, rear type:
    Denim black, Structure cast aluminum with laser etched graphics
  • Brakes, type:
    Front and rear black, Split 7-spoke floating rotors
  • Brakes, caliper type:
    4-piston fixed front and 2-piston floating rear
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    All LED, low beam, high beam and signature position lamp; Integrated, multi-function LED stop/tail/turn signals; Incandescent bullet turn signals
  • Gauges:
    4-inch analog tachometer with digital speedometer, gear, odometer, fuel level, clock, trip and range indication
